Raise3D Pro2 Plus 3D Printer Dual Extruder Fully Enclosed

Raise3D Pro2 Plus 3D Printer Dual Extruder Fully Enclosed

5,400.00 € 7,150.00 € -24%
Brand:
Product Code: 0683813774759
Availability: In Stock
Viewed 233 times

Product Description

Electronic Driven Dual Extrusion with Retracting Hot Ends
Prints complex mechanical parts, supports a variety of multi-material prints improves print speed.
  • High repeatability (<0.005mm, 5 micron)
  • Lightning speed (<1 second switching time)
  • 1.5mm lifting distance, compatible with flexible filaments
  • High reliability (tested >100,000 times)

When Big is Not Big Enough

    Single: 12×12×23.8 inch (305×305×605 mm) Dual: 11×12×23.8 inch (280×305×605 mm)
    • 24/7 Reliability
    • Multiple fail safe systems
    • Industrial grade components



      High Resolution

      Unique motion system for superior part quality and resolution

      • Interchangeable nozzles: 0.2 mm nozzle for finer X/Y detail
      • Precise positioning: 0.78125 micron positioning resolution on X/Y axis
      • Unmatched layer resolution: 0.01 mm layer thickness



        Capable of Printing a Variety of Filaments Up to 300℃

        PLA / ABS / HIPS / PC / TPU / TPE / NYLON / PETG / ASA / PP / PVA / Glass Fiber Infused / Carbon Fiber Infused / Metal Fill / Wood Fill
        Electronic Driven Dual Extrusion with Retracting Hot Ends Prints complex mechanical parts, supports a variety of multi-material prints improves print speed. High repeatability (<0.005mm, 5 micron) Lightning speed (<1 second switching time) 1.5mm lifting distance, compatible with flexible filaments High reliability (tested >100,000 times) When Big is Not Big Enough Single: 12×12×23.8 inch (305×305×605 mm) Dual: 11×12×23.8 inch (280×305×605 mm) 24/7 Reliability Multiple fail safe systems Industrial grade components High Resolution Unique motion system for superior part quality and resolution Interchangeable nozzles: 0.2 mm nozzle for finer X/Y detail Precise positioning: 0.78125 micron positioning resolution on X/Y axis Unmatched layer resolution: 0.01 mm layer thickness Capable of Printing a Variety of Filaments Up to 300℃ PLA / ABS / HIPS / PC / TPU / TPE / NYLON / PETG / ASA / PP / PVA / Glass Fiber Infused / Carbon Fiber Infused / Metal Fill / Wood Fill Intuitive User Experience

        7-inch Touch Screen

        Visual interface / Rapid reviewing / Visual print progress / Full adjustment control New Extruder with Filament Run-out Sensor Effortless, Dependable and Accurate with optical run-out sensors and end stops Better grip: Dual gear driven No slipping: 4× increased torque performance Worry free prints: Optical run-out sensor

        Next Generation Motion Controller

        Best in class reliability / Precise voltage control / Silky smooth movement / Superior thermal performance 400MHz ARM Cortex-M7 32bit RISC FPU Industrial grade components Stand-alone motor driver 256 micro-steps driver system Remote User Interface Access / Monitor / Control Operate efficiently with ideaMaker by connecting wirelessly to your Pro2 Series Printer HEPA Air Filtration Environmentally friendly

        Designed to silently remove nano-particles

        Build Plate System

        Excellent warping prevention / Even heat distribution / Longer lifetime / Easy to remove Aerospace grade material High temperature silicone heating bed Magnetically-held aluminium bed Improved 4+9 points lock system

        Technical Specifications

        General
        Print Technology: FFF Build Volume (W×D×H): – Single Extrusion Print: 12×12×23.8 in / 305×305×605 mm – Dual Extrusion Print: 11×12×23.8 in / 280×305×605 mm Machine Size (W×D×H): 24.4×23.2×43.5 in / 620×590×1105 mm Print Head: Dual-head with electronic lifting system Filament Diameter: 1.75mm XYZ Step Size: 0.78125, 0.78125, 0.078125 micron Print Head Travel Speed: 30 – 150 mm/s Build Plate: Heated aluminum build plate with magnetic holding Max Build Plate Temperature: 110 ºC Heated Bed Material: Silicone Build Plate Leveling: Pre-calibrated leveling Supported Materials: PLA / ABS / HIPS / PC / TPU / TPE / NYLON / PETG / ASA / PP / PVA / Glass Fiber Infused / Carbon Fiber Infused / Metal Fill / Wood Fill Nozzle Diameter: 0.4 mm (Default), 0.2/ 0.6/ 0.8/ 1.0 mm (Available) Max Nozzle Temperature: 300 ºC Connectivity: Wi-Fi, LAN, USB port, Live camera Noise Emission (Acoustic): <50 dB(A) when building Operating Ambient Temperature: 15-30 ºC, 10-90% RH non-condensing Storage Temperature: -25℃ to +55℃, 10-90% RH non-condensing Technical Certifications: CB, CE, FCC, RoHS

        Electrical

        Power Supply Input: 100-240V AC, 50/60Hz 230V @3.3A Power Supply Output: 24V DC, 600 W

        Software

        Slicing Software: ideaMaker Supported File Types: STL/ OBJ/ 3MF Supported OS: WINDOWS/ macOS/ LINUX Machine Code Type: GCODE

        Printer Controller

        User Interface: 7-inch Touch Screen Network: Wi-Fi, Ethernet Resume Print after Power Outage: Firmware recording, no need for battery installation. Protection from any condition Screen Resolution: 1024*600 Motion Controller: ARM Cortex M7.400MHZ FPU Logic Controller: Freescale i.MX6, Quad core 1Ghz ARM processor Memory: 1GB Onboard Flash: 8GB OS: Embedded Linux Ports: USB 2.0*2, Ethernet*1
